MIG/MAG equipment
Torches and components
 |
MXL 150v
MXL 200
MXL 270
MXL 340 |
 |
| |
MXL 150v |
MXL 200 |
MXL 270 |
MXL 340 |
| Gas nozzle standard Ø12 mm |
0700 200 054 |
0700 200 054 |
|
|
| Gas nozzle standard Ø15 mm |
|
|
0700 200 055 |
|
| Gas nozzle standard Ø16 mm |
|
|
|
0700 200 056 |
| Gas nozzle straight Ø16 mm |
0700 200 057 |
0700 200 057 |
|
|
| Gas nozzle straight Ø18 mm |
|
|
0700 200 058 |
|
| Gas nozzle straight Ø19 mm |
|
|
|
0700 200 059 |
| Gas nozzle conical Ø 9.5 mm |
0700 200 060 |
0700 200 060 |
|
|
| Gas nozzle conical Ø11.5 mm |
|
|
0700 200 061 |
|
| Gas nozzle conical Ø12 mm |
|
|
|
0700 200 062 |
| Contact tip Cu W0.6 M6 |
0700 200 063 |
0700 200 063 |
|
|
| Contact tip Cu W0.8 M6 |
0700 200 064 |
0700 200 064 |
|
|
| Contact tip Cu W0.9 M6 |
0700 200 065 |
0700 200 065 |
|
|
| Contact tip Cu W1.0 M6 |
0700 200 066 |
0700 200 066 |
|
|
| Contact tip Cu W0.8 M6 |
|
|
0700 200 068 |
0700 200 068 |
| Contact tip Cu W0.9 M6 |
|
|
0700 200 069 |
0700 200 069 |
| Contact tip Cu W1.0 M6 |
|
|
0700 200 070 |
0700 200 070 |
| Contact tip Cu W1.2 M6 |
|
|
0700 200 071 |
0700 200 071 |
| Nozzle spring |
0700 200 078 |
0700 200 078 |
|
|
| Nozzle spring |
|
|
0700 200 079 |
|
| Tip adaptor M6 MXL 150v |
0700 200 076 |
|
|
|
| Tip adaptor M6 MXL 200 |
|
0700 200 072 |
|
|
| Tip adaptor M6 MXL 270 |
|
|
0700 200 073 |
|
| Tip adaptor M6-Alu MXL 270 |
|
|
0700 200 067 |
|
| Tip adaptor M6, short MXL 340 |
|
|
|
0700 200 074 |
| Tip adaptor M6, long MXL 340 |
|
|
|
0700 200 075 |
| Gas diffusor |
|
|
|
0700 200 080 |
| Steel liner W0.6 - W0.8 2.5 m |
0700 200 099 |
|
|
|
| Steel liner W0.6 - W0.8 3.0 m |
|
0700 200 085 |
0700 200 085 |
0700 200 085 |
| Steel liner W0.6 - W0.8 4.0 m |
|
0700 200 086 |
0700 200 086 |
0700 200 086 |
| Steel liner W0.9 - W1.2 3.0 m |
|
0700 200 087 |
0700 200 087 |
0700 200 087 |
| Steel liner W0.9 - W1.2 4.0 m |
|
0700 200 088 |
0700 200 088 |
0700 200 088 |
| PTFE liner W0.6 - W0.8 3.0 m |
|
0700 200 089 |
0700 200 089 |
0700 200 089 |
| PTFE liner W0.6 - W0.8 4.0 m |
|
0700 200 090 |
0700 200 090 |
0700 200 090 |
| PTFE liner W0.9 - W1.2 3.0 m |
|
0700 200 091 |
0700 200 091 |
0700 200 091 |
| PTFE liner W0.9 - W1.2 4.0 m |
|
0700 200 092 |
0700 200 092 |
0700 200 092 |
|
